General Technical Characteristics

Non-inductive, low equivalent inductance;

High vacuum impregnation treatment, low loss, low temperature resistance;

Foil-type structure, strong inrush resistance and high current impact resistance;

No self-healing failure problem with stable capacity;

Oil-free, explosion-proof available;

Insulators with high strength, fatigue resistance and excellent electrical performance.

Long lifetime ≥200,000h.

Electrical Characteristics

Reference Standard :           IEC 61071, IEC 61881

Climatic Category :               40/85/21

Operating temperature        - 40 to + 70 ℃ (hotspot temperature)

Storage temperature           - 40 to + 85 ℃

Rated Voltage:                     1700Vdc to 10000 Vdc / 1000Vac to 7000 Vac

  Capacitance Range :          0.0010µF ~ 0.1µF

Capacitance Tolerance :       ±5%(J), ±10%(K),

Dissipation Factor :             ≤3×10^-4 Measured at 100 Hz and 20°C

Test Voltage :                       2.0U_N for 10 sec.
