■General Technical Characteristics 一般特性

Metallized polypropylene film

金属化聚丙烯膜

Low loss at high frequency

高频损耗小

Small inherent temperature rise

内部温升小

Plastic case (UL94 V-0), epoxy resin sealing

塑胶外壳（UL94 V-0 ), 阻燃环氧填充

■Electrical Characteristics 电气特性

Reference standard 引用标准:           GB/T 14579 (IEC60384-17)

Climatic Category 气候类别:             55/105/56

Rated Temperature 额定温度:           85°C

Operating Temperature Range:           -40°C ~ 105°C

工作温度范围:                          (+85°C to +105°C: decreasing factor 1.25% per °C for U_R(dc) )

Rated Voltage 额定电压:                160Vdc(90Vac), 250Vdc(160Vac), 400Vdc(200Vac),   630Vdc(250Vac),

1000Vdc(450Vac), 1600Vdc(600Vac), 2000Vdc(700Vac)

Capacitance Range 电容量范围:         0.00056µF ~ 15.0µF

Capacitance Tolerance 电容量偏差:      ±5% (J), ±10%(K)

Dissipation factor 损耗角正切:           ≤10x10^-4 Measured at 1KHz and 20°C.

Test Voltage 耐电压:                   1.6U_R for 5 sec.

Insulation resistance 绝缘电阻:          ≥50 000MΩMeasured at 20°C, 100V and 1 min.
