■ General Technical Characteristics

Self-healing property

良好的自愈性

Excellent stable performance and reliability

性能稳定、可靠性强

■ Electrical Characteristics 电气特性

Reference Standard 引用标准: GB/T 3667.1 (IEC60252-1)

Climatic Category 气候类别: 40/70/21, 40/85/21, 40/105/21

Rated Voltage 额定电压: 110VAC ~ 600VAC

Capacitance Range 电容量范围: 5.0μF ~ 40.0μF

Capacitance Tolerance 电容量偏差: ±5% (J), ±10%(K)

Dissipation Factor 损耗角正切: ≤0.25% Measured at 100Hz

Test Voltage 耐电压: Between Terminals: 2xUN (2S)

Between Terminals to Case: 2 000VAC or 2UN +1 000VAC (60S)

Maximum Permissible Voltage 最高运行电压: 1.1U N

Maximum Permissible Current 最高运行电流: 1.3IN
